Shelf Mount Clamp for Baby Monitor / Camera (1/4"-20 Thread)

A compact, print-in-place style shelf mount clip designed to easily mount a baby monitor, security camera, or small accessory onto a shelf edge, headboard, or desk lip without drilling or adhesive.

Equipped with a standard 1/4"-20 UNC / UNF tripod thread mounting point on top, compatible with almost all standard baby monitor cameras (e.g., Owlet, Nanit, Motorola, Lollipop, EZVIZ, Tapo) and small ball heads.

Features

Universal Fit: Mounts to standard shelves using a flexible/snug C-clamp geometric design.

Standard Thread: Integrated hole/mount for a 1/4"-20 screw to secure your camera securely.

No Screws/Holes Required for Wall: Clamps directly onto existing furniture.

Easy Print: Designed to print clean without complex overhangs when oriented correctly.

Print Settings

Printer Brand: Anycubic / Generic FDM

Rafts: Yes, a small Brim

Supports: No (or minimal tree supports depending on orientation)

Layer Height: 0.2 mm

Infill: 30% (Gyroid or Grid recommended for strength around the clamping curve)

Perimeters/Walls: 3 or 4 walls (crucial for structural strength on the clamp flex point)

Material: PETG recommended (for better long-term elasticity and spring retention), but PLA works fine for static light loads.
